Mineral Insulated Rtd-Transition Joint – Radix/ Ấn Độ

Mineral Insulated RTD sensors with an integrated cable assembly are lightweight and are designed to be easy to connect and disconnect. It comes with rugged transition joint connections and compacted magnesium oxide (MgO), which protects the RTD assembly from vibrations and increases its durability. Built with a SS316 or SS316L sheath, they are designed for a wide range of chemical, food and pharmaceuticals applications. The RTD sensor measures temperatures between -50 and 400°C. Its PTFE insulated cable is rated for a maximum temperature of 250 °C. Its 2, 3 or 4 wire Pt100 RTD element can be constructed in single or dual assembly in Class A or Class B as per the IEC 751 standard for RTD sensors. Optional overall stainless steel braiding on cable can be constructed for protecting cable from mechanical damage and for additional thermal safety. The terminal head of the RTD sensors has a standard 1/2” BSP (F) single cable entry and a single compression cable gland with the option of dual cable entry and double compression glands. A wide range of options can be constructed with Mineral Insulated RTD sensors, such as head-mounted transmitters, connecting cables and thermowells.
Variety of measuring element configurations
Bendable sheath up to 50 meters long
50 mm long non bendable tip
-50 to 400°C range
3, 4, 5, 6 and 8 mm diameters
Different types of terminal heads available
SS316L sheath material
Copper or Nickel conductors
