Series Ila In-Line Ir Sensor - Radix/ Ấn Độ
-Dwyer Series ILA Non-Contact Sensors, measure temperatures from 32 to 932°F (0 to 500°C) and provide a linear 4 to 20 mA, 0 to 50 mV or thermocouple output. The 2-wire signal is compatible with almost any indicator, controller, recorder, data logger, etc., without the need for special interfacing or signal conditioning. They are suitable for most materials such as food, paper, textiles, plastics, leather, tobacco, pharmaceuticals, chemicals, rubber, coal, and asphalt.
See less
Temperature Range:32 to 932ºF (0 to 500ºC).
Accuracy:1% of reading or 1°C whichever is greater.
Emissivity:0.95 (Fixed).
Distance to Target Size Ratio:15:1.
Response Time:240 ms.
Ambient Operating Temperature:32 to 158°F (0 to 70°C).
Power Requirement:24 VDC.
Repeatability:0.5% of reading or 0.5°C whichever is greater.
Outputs:4 to 20 mA, 0 to 5 V, J type thermocouple.Cable Length:3.3 ft (1 m).
Spectral Response:8 to 14 microns.
Housing:Stainless Steel.
Weight:3.35 oz (95 g).
Agency Approval:CE.
Giá: Liên hệ
See less
Temperature Range:32 to 932ºF (0 to 500ºC).
Accuracy:1% of reading or 1°C whichever is greater.
Emissivity:0.95 (Fixed).
Distance to Target Size Ratio:15:1.
Response Time:240 ms.
Ambient Operating Temperature:32 to 158°F (0 to 70°C).
Power Requirement:24 VDC.
Repeatability:0.5% of reading or 0.5°C whichever is greater.
Outputs:4 to 20 mA, 0 to 5 V, J type thermocouple.Cable Length:3.3 ft (1 m).
Spectral Response:8 to 14 microns.
Housing:Stainless Steel.
Weight:3.35 oz (95 g).
Agency Approval:CE.
Giá: Liên hệ
